Analysis on the Characteristics of Water, Energy and Food Network in Guangdong Province
-
摘要: 广东省人口和产业高度集聚,对水资源-能源-粮食(WEF)依赖程度高,资源供需矛盾日益凸显,合理配置WEF资源,实现资源可持续利用具有重要现实意义.本研究基于复杂网络方法,构建广东省2007、2012、2017年的WEF资源网络模型,通过探索网络拓扑性质,挖掘网络关键节点和关键路径,作为资源优化配置的重点关注对象.结果表明:(1)广东省WEF资源网络具备小世界属性,能源网络的小世界属性最强,水资源网络最弱,关键节点和关键边的调控均会对WEF资源网络形成较大影响.(2)农业、食品和烟草业、化学产品业、电力、热力的生产和供应业、建筑业、通信设备、计算机和其他电子设备制造业等关键节点具备较大点强度,其资源调控对广东省水资源、能源、粮食的节约效应显著.(3)电气机械和器材制造业、建筑业、通信设备、计算机和其他电子设备制造业在WEF资源网络中处于枢纽位置,其资源节约效应可快速传递至整个网络.(4)农业→食品和烟草业、农业→纺织业、食品和烟草→住宿和餐饮业等边频繁出现于WEF资源网络的关键路径之中,改变其资源流通量,可显著改变所在关键路径甚至整个WEF资源网络的流通量.Abstract: With a high concentration of population and industries, Guangdong Province is highly dependent on WEF resources, and the contradiction between supply and demand of resources is increasingly prominent. It is of great practical significance to rationally allocate WEF resources and realize sustainable utilization of resources. Based on the complex network method, this study constructed the WEF resource network model of Guangdong Province in 2007, 2012 and 2017. By exploring resource network topology, key nodes and critical paths of the network were discovered, which were the focus of resource optimization allocation. The results show that: (1) WEF resource networks in Guangdong Province had small-world attribute, the energy network had the strongest small-world attribute, and the water resource network had the weakest small-world attribute. The regulation of key nodes and key edges will have a great influence on WEF resource networks. (2) Key nodes such as agriculture, food and tobacco industry, chemical product industry, electricity and heat production and supply industry, construction industry, communication equipment, computer and other electronic equipment manufacturing industry had relatively high strength, and their resource regulation played a significant role in multiple saving of WEF resources in Guangdong Province. (3) The electrical machinery and equipment manufacturing industry, construction industry, communication equipment, computer and other electronic equipment manufacturing industry had hub positions in the WEF resource network, and their resource saving effect could be quickly transmitted to the whole network. (4) Agriculture→food and tobacco industry, agriculture→textile industry, food and tobacco→accommodation and catering industry frequently appeared in the critical paths of WEF resource network. Changing their resources circulation flow could significantly change the critical path or even the circulation flow of the whole WEF resource network.
-
Key words:
- water-energy-food /
- resource network /
- key node /
- critical path /
- Guangdong Province
-
表 1 广东省经济系统42部门名称
行业编号 行业名称 行业编号 行业名称 S1 农林牧渔产品和服务 S22 其他制造产品 S2 煤炭采选产品 S23 废弃资源和废旧材料回收加工品 S3 石油和天然气开采产品 S24 金属制品、机械和设备修理服务 S4 金属矿采选产品 S25 电力、热力的生产和供应 S5 非金属矿和其他矿采选产品 S26 燃气生产和供应 S6 食品和烟草 S27 水的生产和供应 S7 纺织品 S28 建筑 S8 纺织服装鞋帽皮革羽绒及其制品 S29 批发和零售 S9 木材加工品和家具 S30 交通运输、仓储和邮政 S10 造纸印刷和文教体育用品 S31 住宿和餐饮 S11 石油、炼焦产品和核燃料加工品 S32 信息传输、软件和信息技术服务 S12 化学产品 S33 金融 S13 非金属矿物制品 S34 房地产 S14 金属冶炼和压延加工品 S35 租赁和商务服务 S15 金属制品 S36 科学研究和技术服务 S16 通用设备 S37 水利、环境和公共设施管理 S17 专用设备 S38 居民服务、修理和其他服务 S18 交通运输设备 S39 教育 S19 电气机械和器材 S40 卫生和社会工作 S20 通信设备、计算机和其他电子设备 S41 文化、体育和娱乐 S21 仪器仪表 S42 公共管理、社会保障和社会组织 表 2 广东省WEF资源网络相关指标
水资源 能源 粮食 参量 2007 2012 2017 2007 2012 2017 2007 2012 2017 平均聚类系数 0.46 0.49 0.43 0.47 0.47 0.48 0.42 0.44 0.45 平均路径长度 2.06 1.97 2.06 2.12 2.01 2.08 2.27 2.04 2.05 同规模随机网络聚类系数 0.21 0.22 0.22 0.19 0.19 0.19 0.17 0.19 0.19 同规模随机网络最短路径长度 1.74 1.71 1.70 1.79 1.82 1.80 1.92 1.84 1.83 小世界指数 1.90 1.96 1.60 2.06 2.25 2.16 2.09 2.17 2.11 表 3 WEF资源网络度数前十位的节点
部门 2007 部门 2012 部门 2017 S12 129 S12 130 S12 131 S10 117 S10 114 S30 108 S15 99 S25 106 S10 107 S25 98 S30 103 S20 88 S31 92 S31 96 S25 87 S30 90 S29 81 S15 81 S19 85 S35 80 S35 78 S20 81 S20 77 S19 76 S35 79 S19 73 S31 73 S14 60 S15 67 S29 72 表 4 广东省WEF资源网络关键路径及其权重
关键路径 关键路径权重 2017年水资源网络 S1→S6→S31→S35→S29→S20→S19 9.72×109 m3 S1→S7→S8→S10→S33→S29→S20→S19 2.45×109 m3 S12→S27→S28 2.20×109 m3 网络总边权 4.55×1010 m3 2017年能源网络 S11→S30→S29→S20→S19 1.10×106 TJ S4→S14→S15→S19→S20 1.08×106 TJ S15→S17→S20→S19 1.02×106 TJ 网络总边权 1.08×107 TJ 2017年粮食网络 S1→S6→S31→S35→S29→S20→S19 6.09×106吨 S1→S7→S8→S10→S33→S29→S20→S19 1.35×106吨 S1→S9→S28 8.07×105吨 网络总边权 1.89×107吨 2012年水资源网络 S1→S6→S31→S33→S29→S28 8.37×109 m3 S27→S25→S13→S28 3.56×109 m3 S27→S6→S31→S33→S29→S28 2.65×109 m3 网络总边权 4.88×1010 m3 2012年能源网络 S3→S25→S13→S28 1.21×106 TJ S4→S14→S19→S20 1.08×106 TJ S3→S11→S35→S33→S29→S28 9.18×105 TJ 网络总边权 1.38×107 TJ 2012年粮食网络 S1→S6→S31→S33→S29→S28 4.95×106吨 S1→S7→S8→S9→S28 1.12×106吨 S1→S12→S10→S33→S29→S28 8.58×105吨 网络总边权 1.67×107吨 2007年水资源网络 S1→S6→S31→S35→S12→S20→S19 9.23×109 m3 S27→S1→S6 7.17×109 m3 S37→S27→S28→S34 4.65×109 m3 网络总边权 4.61×1010 m3 2007年能源网络 S4→S14→S19→S20 1.39×106 TJ S25→S13→S28→S34 8.36×105 TJ S11→S25→S28→S34 8.31×105 TJ 网络总边权 1.16×107 TJ 2007年粮食网络 S1→S6→S31→S35→S12→S20→S19 4.72×106吨 S1→S31→S35→S12→S20→S19 1.31×106吨 S1→S7→S8 8.27×105吨 网络总边权 1.42×107吨 -
