以新能源为主体的新型电力系统模型体系和同步稳定研究初步的综述

占萌; 张亚耀; 马锐

doi:10.12202/j.0476-0301.2023146

以新能源为主体的新型电力系统模型体系和同步稳定研究初步的综述

doi: 10.12202/j.0476-0301.2023146

华中科技大学电气与电子工程学院，华中科技大学强电磁工程与新技术国家重点实验室，华中科技大学电力安全与高效湖北省重点实验室，430074，武汉

基金项目: 国家自然科学基金资助项目(U22B6008, 12075091)

详细信息

通讯作者:
占萌(1974—), 男, 博士, 教授. 研究方向: 新型电力系统稳定与控制. E-mail：zhanmeng@hust.edu.cn

中图分类号: TM712
计量
- 文章访问数: 23
- HTML全文浏览量: 15
- PDF下载量: 5
- 被引次数: 0
出版历程
- 收稿日期: 2023-07-30
- 网络出版日期: 2023-11-15

Preliminary study on Model Framework and Synchronous Stability of Renewable-dominated New-type Power Systems

School of Electrical and Electronic Engineering，State Key Laboratory of Advanced Electromagnetic Engineering and Technology，Hubei Electric Power Security and High Efficiency Key Laboratory，Huazhong University of Science and Technology，430074，Wuhan，Hubei，China

摘要

摘要: 随着新能源的快速发展和以新能源为主体的新型电力系统的快速建设，现代电力系统动态特性及同步稳定内涵愈加丰富复杂. 本文首先简单回顾传统电力系统的发展历程及新型电力系统的研究现状. 然后，基于整体论与还原论相结合的研究思路，根据新型电力系统多时间尺度的特性，分别在各个时间尺度（包括交流电流控制，直流电压控制和机电时间尺度）建立含永磁同步风力发电机，双馈式感应风力发电机和光伏三种典型新能源装备(节点)以及交流输电线路(网络)模型，并分析节点与网络的机网接口关系，尝试建立新型电力系统动态模型体系. 最后，讨论和揭示新型电力系统同步稳定内涵. 本文将有助于加深研究人员对以新能源为主体的新型电力系统动态的基本认识，促进电气工程，复杂系统及统计物理相关专业跨学科研究和交流.
- 可再生能源 /
- 以新能源为主体的新型电力系统 /
- 非线性动力学 /
- 多时间尺度分析 /
- 同步稳定.
Abstract: With rapid development of renewable energy and acceleration of construction of renewable-dominated new-type power systems, the dynamic characteristics and synchronous stability of modern power systems become much more complicated. This review paper first briefly introduces the development of the traditional power systems and the research status of the renewable-dominated new-type power systems. Then, based on the key method of combined holism and reductionism, three typical renewable energy equipment (nodes) including permanent magnetic synchronous generator, double-fed induction generator, and photovoltaic and the AC transmission line (network) models are established within the three timescales (including the AC current control, DC-link voltage control, and electromechanical timescales) according to the multi-timescale characteristics of the new-type power systems. At the same time, the machine-network interface relationship between the nodes and network is uncovered. The dynamic model framework of the new-type power systems is preliminarily established. Finally, this paper reveals the synchronous stability mechanism of the new-type power systems. This paper could help deepen our understanding of the dynamics of the renewable-dominated new-type power systems and promote interdisciplinary collaborative research among electrical engineering, complex systems and statistical physics on these fundamental problems.
- renewable energy /
- renewable-dominated new-type power systems /
- nonlinear dynamics /
- multi-timescale analysis /
- synchronization stability.
