Luminescence enhancement mechanism of Au coreshell nanoparticles (Au@SiO2)on Europium
-
摘要: 为了增强稀土有机薄膜的发光效果，在制备稀土发光薄膜过程中引入了金纳米核-壳结构（Au@SiO2）．利用滴铸法将不同物质的量浓度的Au@SiO2滴在石英片上；利用旋涂法将Eu(dbm)3phen：聚甲基丙烯酸甲酯(PMMA)： CH2Cl2混合溶液旋涂在石英片上，制备成薄膜样品．通过对薄膜样品的性能表征后发现：引入Au@SiO2后可增强薄膜的发光强度；激发和发光增强因子最大分别为279.1%和222.9%，同时延长了薄膜样品的荧光寿命．将Au@SiO2引入稀土发光薄膜的制备过程中，能够有效地提升薄膜的发光性能，应用潜力较好．
-
关键词:
- 金纳米核-壳结构(Au@SiO2) /
- Au@SiO2@Eu:PMMA发光薄膜 /
- 发光增强 /
- 表面等离子体
Abstract: To enhance the luminescence effect of rare-earth organic thin films, gold nano core-shell structures (Au@SiO2) were introduced during the preparation process of rare-earth luminescent films. Using the drop-casting method, Au@SiO2 nanostructures with different molar concentrations were applied onto quartz slides; subsequently, a mixture of Eu(dbm)3phen: PMMA:CH2Cl2 was spin-coated onto the quartz slides to fabricate thin film samples. Post-characterization of these samples revealed that introducing Au@SiO2 significantly enhanced the luminescence intensity of the films. The maximum excitation and luminescence enhancement factors were 279.1% and 222.9% respectively, and the fluorescent lifetime of the film samples was extended as well. Incorporating Au@SiO2 into the fabrication process of rare-earth luminescent films effectively improves their luminous performance, showing promising application potential. -
图 1 滴铸Au@SiO2水溶液样品的石英片的SEM图像
注：加速工作电压为10 kV；实际样品尺寸为5.0 mm；放大倍数为50 000倍；次级电子（上探头接收二次电子信号）．
-
[1] ZHAO G Y,XU L Z,MENG S H,et al. Facile preparation of plasmon enhanced near-infrared photoluminescence of Er3+-doped Bi2O3-B2O3-SiO2 glass for optical fiber amplifier[J]. Journal of Luminescence,2019,206:164 doi: 10.1016/j.jlumin.2018.10.026 [2] 姚云华. 稀土离子上转换发光的超快光场调控[D]. 上海:华东师范大学,2018 [3] WANG C,NIE X G,SHI Y,et al. Direct plasmon-accelerated electrochemical reaction on gold nanoparticles[J]. ACS Nano,2017,11(6):5897 doi: 10.1021/acsnano.7b01637 [4] 闫建红,黄俐研,梁慧,等. 种子乳液聚合法制备聚苯胺导电复合物[J]. 北京师范大学学报(自然科学版),2010,46(5):589 [5] XIAN Y H,CAI Y,SUN X Y,et al. Refractory plasmonic metal nitride nanoparticles for broadband near-infrared optical switches[J]. Laser & Photonics Reviews,2019,13(6):1900029 [6] ZENG Y G,WANG M Y,FENG G P,et al. Laser speckle imaging based on intensity fluctuation modulation[J]. Optics Letters,2013,38(8):1313 doi: 10.1364/OL.38.001313 [7] 梁沁. 不同价态铕(Eu)离子的发光机理及应用[D]. 天津:南开大学,2005 [8] DONG H,SUN L D,YAN C H. Local structure engineering in lanthanide-doped nanocrystals for tunable upconversion emissions[J]. Journal of the American Chemical Society,2021,143(49):20546 doi: 10.1021/jacs.1c10425 [9] YU Y L,CHEN D Q,WANG Y S,et al. Enhanced photoluminescence of Eu3+ induced by energy transfer from In2O3 nano-crystals embedded in glassy matrix[J]. Physical Chemistry Chemical Physics,2009,11(39):8774 doi: 10.1039/b907065f [10] ZHOU W,HE Z Q,ZHAO X J. Effect of Ag nanoparticles doped in polymethyl methacrylate matrix for luminescent solar concentrator[J]. Key Engineering Materials,2014,599:291 doi: 10.4028/www.scientific.net/KEM.599.291 [11] ALI U,KARIM K J B A,BUANG N A. A review of the properties and applications of poly (methyl methacrylate) (PMMA)[J]. Polymer Reviews,2015,55(4):678 doi: 10.1080/15583724.2015.1031377 [12] 宋增福. 原子光谱及晶体光谱原理与应用[M]. 北京:科学出版社,1987 [13] ZHU Y S,WANG Y H,ZHU J Y,et al. Plasmon multiwavelength-sensitized luminescence enhancement of highly transparent Ag/YVO4:Eu3+/PMMA film[J]. Journal of Luminescence,2018,200:158 doi: 10.1016/j.jlumin.2018.03.081 [14] WANG Q R,ZHANG J,SANG X,et al. Enhanced luminescence and prolonged lifetime of Eu-PMMA films based on Au@SiO2 plasmonic hetero-nanorods[J]. Journal of Luminescence,2018,204:284 doi: 10.1016/j.jlumin.2018.08.033 [15] 龙江迷,陈晓波,赵国营,等. Ag@SiO2核壳纳米颗粒对Eu-PMMA薄膜的发光增强效应[J]. 中国光学,2021,14(6):1341 [16] WILEY B,SUN Y G,MAYERS B,et al. Shape-controlled synthesis of metal nanostructures:the case of silver[J]. Chemistry,2005,11(2):454 doi: 10.1002/chem.200400927 -
